Audison Forza AF M12.14 bit ADSP
Audison AF M12.14 bit 12 channel ADSP amp processor 12CH Amp with 14CH DSP12 x 60w or 6 x 180w bridge modeDSP working operation at 24 bit/96 kHzLatest generation of…
$3,499.00
Audison AF M12.14 bit
12 channel ADSP amp processor
12CH Amp with 14CH DSP
12 x 60w or 6 x 180w bridge mode
DSP working operation at 24 bit/96 kHz
Latest generation of ADT (Audison D-Class)
- Improved audio performance and power thanks to the latest generation of ADT (Audison D-Class) technology
- Unbeatable power/volume ratio up to 0.68 W RMS/cm³ reaching 82% of efficiency
- Next-generation bit Drive software platform
- Hi-Res compatibility performance, with an extended audio band up to 40 kHz, made possible by and DSP working operation at 24 bit/96 kHz
- Maximum versatility thanks to the possibility of using the bridging option for each pair of power outputs
- Up to 14 output channels (12 amplified, 2 native pre-out outputs, 4 optional pre-outs) controlled by the DSP to expand the system with other amplifiers
- 8 high/low-level inputs (and an optical Toslink digital input) support total connectivity even with the most complex OEM systems
- Extension card slot (additional 4 analog or 1 digital inputs)
- Electrical signal analysis for each input channel ensures proper integration and correction
- Acoustic analysis (with your USB microphone) integrates the response graph into the equalizer display. This ensures efficient tuning and great sound!
- Advanced signal routing options allow the technician to go beyond the predefined system definitions in the Configuration Wizard
Specifications
| POWER SUPPLY | |
| Nominal power supply voltage / fuse: | 11 ÷ 15 VDC / 2 x 30A |
| Pulse operating voltage: | 6.5 ÷ 17.5 VDC |
| Idling current: | 1.68 A |
| Standby current draw: | 1.7 mA |
| Consumption @ 14.4 VDC, Minimum load impedance (Max Musical Power): | 45 A |
| Remote IN: | 4 ÷15 VDC (1 mA) |
| Remote OUT: | 6.5 ÷15 VDC (150 mA) |
| ART – Automatic Remote Turn on/off from Speaker-In | 1.5 VDC |
| Efficiency @ rated power (RMS) @14.4 VDC, 1% THD,4Ω, All Channels: | 80% |
| AMPLIFIER STAGE | |
| Distortion – THD+N @ 1 KHz, 4Ω, 70% Rated Power: | 0.03% |
| Damping factor @ 1 kHz , 4Ω, 2 VRMS: | 80 |
| Bandwidth @ -3 dB: | 10 Hz ÷ 42 kHz |
| S/N ratio (A weighted @ 1 V Input, Rated Power) Master Input: | 98 dBA |
| S/N ratio (A weighted @ Rated Power) Optical Input: | 105 dBA |
| Minimum load impedance: | 12Ch: 2Ω |
| 6Ch – (Bridge 1/2; 3/4; 5/6; 7/8; 9/10; 11/12): 4Ω | |
| Output Continuous Power (RMS) @14.4 VDC, 1% THD: | |
| • 12 Ch @ 4Ω: | 60 W x 12 |
| • 12 Ch @ 2Ω: | 90 W x 12 |
| • 4Ch (Bridge 1/2; 3/4; 5/6; 7/8; 9/10; 11/12) @ 4Ω: | 180 W x 6 |
| CEA SPECIFICATIONS | |
| Output power @ 4Ω, 1% THD+N, 14.4 V: | 45 W |
| SN ratio (ref. 1 W output): | 75.5 dB |
| INPUTS / OUTPUTS | |
| Pre-In (8 Ch): | 0.6 ÷ 6 VRMS (15 kΩ Imp.) |
| Speaker-In (8 Ch + additional 4 Ch with optional F4IN card): | 2.2 ÷ 22 VRMS (5 Ω Imp.) |
| Digital IN: | 1 x Optical S/PDIF; Max 192 kHz / 24 bit + 1 x Optical/Coaxial S/PDIF with optional F2O card |
| DSP Preout (2 Ch): | 5V RMS |
| DIGITAL SIGNAL PROCESSOR | |
| Audio DSP and converters: | Analog Devices ADAU1467 automotive qualified audio processor. |
| Processing @ 96 kHz.Analog Devices 3 x ADAU1978 (4ch) and ADAU1966A (16ch) A/D and D/A converters (24 bit/192 kHz) providing very high level performance | |
| Filter type: | Full / High-Pass / Low-Pass / Band-Pass |
| Filter mode and slope: | Linkwitz-Riley @ 12/24/36/48 dB/Oct. |
| Butterworth @ 6/12/18/24/30/36/42/48 dB/Oct. | |
| Bessel @ 6/12/18/24/30/36/42/48 dB/Oct. | |
| Chebyshev @ 6/12/18/24/30/36/42/48 dB/Oct. | |
| QLP @ 6 dB/Oct. | |
| Crossover frequency: | 20 Hz ÷ 20 kHz |
| Phase control: | 0° / 180°, All-Pass filters |
| Analog Input Equalizer (20 Hz ÷ 20 kHz): | 12 Biquad + Delay |
| Output Equalizer: | Parametric/Graphic Biquad: 15 poles, 20 Hz ÷ 20 kHz |
| Input and Output Real Time Audio Monitor: | RTA |
| Time Alignment Distance: | 0 ÷ 510 cm / 0 ÷ 200.8 inches |
| Time Alignment Delay: | 0 ÷ 15 ms |
| CONTROL CONNECTIONS | |
| Audison DRCC port: | Input for DRCC remote control (Optional) |
| Audison ADC port: | Manage other Audison devices that support this standard |
| Control 1 wire: | Customizable functions (+ 12 V activated) |
| Control 2 wire: | Customizable functions (+ 12 V activated) |
| GENERAL REQUIREMENTS | |
| PC connections: | Micro USB 1.1 / 2.0 / 3.0 Compatible |
| Software/ PC requirements: | Windows 10, Windows 11 (min. res. 1024 x 768 |
| Ambient operating temperature range: | 0 °C to 55 °C (32 °F to 131 °F) |
| SIZE / WEIGHT | |
| Max size W x H x D (mm/inch): | 240 x 47 x 156 / 9.44 x 1.85 x 6.14 |
| Weight (kg/lb): | 2,04 / 4.49 |
